Optimization of Motor Rotor: Slot Shape, Frame Size, Rotor Diameter
There has been, in recent years, an effort to make cast copper rotors for industrial use induction motors. The objective is to make motors more efficient because of the higher conductivity of copper. In addition, the reduced losses in such motors may lead to better design flexibility and therefore motors that are more compact. In this paper we examine the tradeoff between running efficiency and starting performance.
In order to understand how induction motors work it is necessary to have a good model for the conduction properties of the conductors in the slots of the rotor. We employ a simple model that has been developed for this purpose. We propose to examine the frequency response of the rotor bar impedance for indications of how the motor will work, taking into account not only running efficiency and starting performance but also stray load losses which are also affected by rotor bar impedance.
The characteristic curve with higher resistance would, for all load torques, operate at a somewhat lower running speed and hence higher slip and lower efficiency than the machine with the lower resistance. On the other hand, starting torque is lower for the low resistance rotor and this might lead to unsatisfactory performance in some applications.
The use of copper as the conductor of induction motor rotors would typically lead to improvements in efficiency, relative to motors using aluminum. This is often done in large motors in which squirrel cages are fabricated from bars of material brazed to end rings. In such machines it is common to employ 'starting' bars of higher resistivity material.
